Full Description
A huge number of guitars come equipped with standard humbuckers, but the fun doesn’t have to stop there. Using a humbucker-sized P90 can offer a wider, more open sound, and open up new musical avenues.
Powered by twin Alnico 2 bar magnets, and with a strong bass and crisp highs, the Rebel 90 finds the sweet spot between single coil and humbucker tonalities.
Nickel Silver Covers on all models. #3-48 screws and springs supplied and a full installation guide supplied.
Neck 7.6k / Bridge 7.9k, Alnico 2
Tech Specs
| Rebel 90 Neck | Rebel 90 Bridge | ||
|---|---|---|---|
| Model | R90V-N | R90V-B | |
| Magnet | Twin Alnico 2 Bar | Twin Alnico 2 Bar | |
| DCR | 7.6k | 7.9k | |
| Inductance | 3.4H | 4.2H | |
| Hookup Wire | 2-Conductor | 2-Conductor | |
| Winding Direction | Counter-Clockwise | Clockwise | |
| Polarity | South Pole Up | North Pole Up |
Dimensions
Wiring Diagrams
- 1 Rebel 90, 1 Humbucker / 1 Vol / 1 Tone / 3-Way Toggle / Push-Pull Coil Split
- 1 Rebel 90, 1 Humbucker / 1 Vol / 1 Tone / 3-Way Toggle
- 1 Rebel 90, 1 Humbucker, 2 Volume, 2 Tone
- 1 Rebel 90 / 1 Vol / 1 Tone
- 1 Rebel 90 / 1 Vol
- 2 Rebel 90s / 2 Vol / 2 Tone / 3-Way Toggle
- 2 Rebel 90s / 1 Vol / 1 Tone / 3-Way Toggle
Full Description
A huge number of guitars come equipped with standard humbuckers, but the fun doesn’t have to stop there. Using a humbucker-sized P90 can offer a wider, more open sound, and open up new musical avenues.
Powered by twin Alnico 2 bar magnets, and with a strong bass and crisp highs, the Rebel 90 finds the sweet spot between single coil and humbucker tonalities.
Nickel Silver Covers on all models. #3-48 screws and springs supplied and a full installation guide supplied.
Neck 7.6k / Bridge 7.9k, Alnico 2
Tech Specs
| Rebel 90 Neck | Rebel 90 Bridge | ||
|---|---|---|---|
| Model | R90V-N | R90V-B | |
| Magnet | Twin Alnico 2 Bar | Twin Alnico 2 Bar | |
| DCR | 7.6k | 7.9k | |
| Inductance | 3.4H | 4.2H | |
| Hookup Wire | 2-Conductor | 2-Conductor | |
| Winding Direction | Counter-Clockwise | Clockwise | |
| Polarity | South Pole Up | North Pole Up |
Dimensions
Installation & Wiring Diagrams
- 1 Rebel 90, 1 Humbucker / 1 Vol / 1 Tone / 3-Way Toggle / Push-Pull Coil Split
- 1 Rebel 90, 1 Humbucker / 1 Vol / 1 Tone / 3-Way Toggle
- 1 Rebel 90, 1 Humbucker, 2 Volume, 2 Tone
- 1 Rebel 90 / 1 Vol / 1 Tone
- 1 Rebel 90 / 1 Vol
- 2 Rebel 90s / 2 Vol / 2 Tone / 3-Way Toggle
- 2 Rebel 90s / 1 Vol / 1 Tone / 3-Way Toggle
Media
I bought them as a replacement for my Les Paul Humbuckers. They are what I was really expecting and at a great quality-price ratio. I highly recommend them.
Really lovely sounding pickups and a big step up from other humbucker-sized p90s I have tried.
Nice build quality at beautiful sound.
https://youtu.be/eS-cSCAJ6Lg?si=Nju3VNH6tFIlmXM_
I upgraded my 2008 epiphone les Paul studio with a rebel 90 in the neck and a Birmingham humbucker in the neck. They both sound amazing. Probably the best value pickups on the market. Well impressed
OK I invested in a set of H90 Rebels about 8 years ago now. Replaced the pups in my Washburn Chicago tour 24 and have never looked back. Great clarity with bite. Not scratchy ...bold yet nice balanced bass also. I recently jammed with some old band mates and they were sufficiently impressed with the sound these pups and the guitar delivered...I could see the other guitarist who has some very nice and $ guitars looking more than a little impressed.
The pickups are fantastic, they have unparalleled clarity and great output. They were delivered just a couple of days after I had ordered. Top marks, will buy again.
